Camera
Beeldsensor 1/1.8" Progressive Scan CMOS
Max. Resolutie 2688 × 1520
Minimale verlichting
Kleur: 0.0005 Lux @ (F1.2, AGC AAN), Z/W: 0.0001 Lux @ (F1.2, AGC AAN), Z/W: 0 Lux
met IR
Sluitertijd 1 s tot 1/100.000 s
Dag & Nacht IR-cutfilter, blauwglazen module (minder ghosting-effect)
Hoekaanpassing Pan: 0° tot 355°, tilt: 0° tot 75°, rotatie: 0° tot 355°
Lens
Type lens Vari-focus lens, gemotoriseerde lens, 2.8 tot 12 mm en 8 tot 32 mm optioneel
Brandpuntsafstand & FOV
2.8 tot 12 mm:
horizontale FOV 114.6° tot 41.8°, verticale FOV 59.3° tot 23.6°, diagonale FOV 141.3° tot 48.1°
8 tot 32 mm:
horizontale FOV 42.5° tot 15.2°, verticale FOV 23.4° tot 8.7°, diagonale FOV 49.7° tot 17.3°
Focus Auto, Semi-auto, Handmatig
Iristype P-iris
Diafragma 2.8 tot 12 mm: F1.38 tot F2.53, 8 tot 32 mm: F1.7 tot F1.73
DORI
2.8 tot 12 mm:
D (Detectie): 149.0 m, O (Observeren): 59.1 m, R (Herkennen): 29.8 m, I (Identificeren): 14.9 m
8 tot 32 mm:
D (Detectie): 400 m, O (Observeren): 158.7 m, R (Herkennen): 80 m, I (Identificeren): 40 m
De DORI-waarden zijn berekend met behulp van pixeldichtheden voor verschillende gebruikstoepassingen zoals aanbevolen door de EN 62676-4 norm.
Verlichting
Type aanvullend licht IR
Bereik aanvullend licht 2.8 tot 12 mm: Monitoring: 40 m; 8 tot 32 mm: Monitoring: 60 m
Slim aanvullend licht Ja
IR-golflengte 850 nm
AI Open Platform
Model specificatie
Tot 4 modellen,
Modeltype: detectiemodel, classificatiemodel, gemengd model (detectie en classificatie)
Video
Hoofdstream
Monitoringmodus:
50 Hz: tot 50 fps (2688 × 1520, 1280 × 720), tot 100 fps (1920 × 1080)
60 Hz: tot 60 fps (2688 × 1520, 1280 × 720), tot 120 fps (1920 × 1080)
*Hoge framerate wordt alleen ondersteund in monitoringmodus.
Slimme modus:
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Substream
50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480)
Derde stream
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Vierde stream
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Vijfde stream
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480)
Videocompressie
Hoofdstream: H.265+/H.265/H.264+/H.264
Substream: H.265/H.264/MJPEG
Derde stream: H.265/H.264
Vierde stream: H.265/H.264/MJPEG
Vijfde stream: H.265/H.264/MJPEG
Video bitrate 32 Kbps tot 8 Mbps
H.264 Type Baseline Profile, Main Profile, High Profile
H.265 Type Main Profile
Bitratecontrole CBR, VBR
Scalable Video Coding (SVC) H.264 en H.265 codering
Region of Interest (ROI) 4 vaste regio’s per stream
Target Cropping Ja
e-PTZ Ondersteunt Patrouille en Auto Tracking instellingen
Audio
Audiotype Mono
Audiocompressie G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio bitrate
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 tot 192 Kbps (MP2L2)/8 tot 320 Kbps (MP3)/16 tot 64 Kbps (AAC-LC)
Audiosamplingrate 8 kHz/16 kHz/32 kHz/48 kHz
Omgevingsruisonderdrukking Ja
Netwerk
Protocollen
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,
PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS,
WebSocket, WebSockets
Gelijktijdige liveweergave Tot 20 kanalen
API ISAPI, SDK, ISUP, OTAP, ONVIF (Profiel S, G, T, M)
Gebruiker/Host
Tot 32 gebruikers
3 gebruikersniveaus: beheerder, operator en gebruiker
Beveiliging
Wachtwoordbeveiliging, complex wachtwoord, HTTPS-versleuteling, 802.1X-authenticatie (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP-adresfilter, basis- en digestauthenticatie voor HTTP/HTTPS, WSSE en digestauthenticatie voor Open Network Video Interface, RTP/RTSP OVER HTTPS, timeout-instellingen, beveiligingslogboek, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 niveau 2), AES128/256
Client iVMS-4200, Hik-Connect, Hik-Central
Netwerkopslag
NAS (NFS, SMB/CIFS), Automatische Netwerk Aanvulling (ANR),
Ondersteunt encryptie en gezondheidsdetectie bij gebruik met high-end Hikvision geheugenkaart
Webbrowser
Plug-in nodig voor liveweergave: IE 10, IE 11
Plug-in vrije liveweergave: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+
Lokale service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Afbeelding
Instelbaar beeld: rotatiemodus, verzadiging, helderheid, contrast, scherpte, witte balans, AGC – aanpasbaar via clientsoftware of browser
Dag/Nacht-schakelaar: Dag, Nacht, Auto, Schema, Alarmtrigger
Wide Dynamic Range (WDR): 150?dB
Beeldverbetering: BLC, HLC, 3D-DNR, vervormingscorrectie, defog
SNR?≥?52?dB
Privacymasker: 8 instelbare polygonale maskers
Overlay: LOGO-functie op video met 128×128 px 24-bit BMP-formaat
Beeldstabilisatie: EIS
Interface
Video-uitgang: 1?Vp-p composietuitgang (75?Ω/CVBS) (alleen voor debugging)
Ethernet: 1?RJ45 10/100/1000?M zelf-adaptieve poort
On-board opslag
Sleuf voor microSD/microSDHC/microSDXC-kaart tot 1?TB
Met -1T-optie: ingebouwde 1?TB SSD (model met 1?TB)
Ingebouwde microfoon: ja, 2 stuks
Ingebouwde speaker: 1,5?W max., maximaal geluidsdrukniveau 98?dB, bereik 10?m
RS-485: 1 poort (Half duplex, HIKVISION, Pelco-P/D, zelf-adaptief)
Audio
1 ingang (line-in), 3,5?mm, max. 3,3?Vpp, 4,7?kΩ, niet-gebalanceerd
1 uitgang (line-out), 3,5?mm, max. 3,3?Vpp, 100?Ω, niet-gebalanceerd, mono
Alarm en besturing
Alarm: 2 ingangen, 2 uitgangen (max. 24?VDC/24?VAC, 1?A)
Reset-knop: ja
Evenementen
Basisgebeurtenissen: bewegingsdetectie (inmiddels met target-type selecties), videomanipulatiealarm, kwaliteitsdiagnose, uitzonderingen (netwerk, IP-conflict, illegale login, herstart, HDD vol/fout), vibratiedetectie
Slimme gebeurtenissen: scèneverandering, audio-exceptiedetectie, defocusdetectie
Linkage-acties: upload naar FTP/NAS/kaart, waarschuwing aan meldkamer, e-mail, alarmuit, opname, capture, hoorbare waarschuwing
Deep Learning-functies
Multi-target detectie (mens, gezicht, voertuig), 7 gezichts-, 13 lichaams- en 2 voertuigkenmerken
Tel-functies: lijnovergang per type target
Dynamisch mozaïekmasker
Gezichtscaptatie & vergelijking
Detecteert tot 120 gezichten tegelijk, 40 gezichten/frame, upload tot 10/sec, swing: ±60° pan, ±30° tilt
Upload met achtergrond & close-up, best shot & quick shot
Dynamisch mozaïek
7 gezichtskenmerken
Vergelijking: tot 10 bibliotheken, 30.000 gezichten elk, totaal 150.000, bibliotheek-encryptie
Perimeterbescherming
Detectie: lijnoverschrijding, inbraak, gebiedsentree/-exit
Geselecteerde target-types (mens/voertuig), gecombineerde alarmtrigger
People Counting & wachtrijbeheer
Multi-Dimension People Counting, instelbare triggers, dagelijks/wekelijkse/maand/jaar-rapporten
Dedupleren op basis van gezicht, attributen, tijd
Queue Management: tot 8 regio’s, detectie wachttijd en lengte, rapportage en data-export
Heat Map
Visueel kaart van bezoekersaantallen of verblijftijd
Ruimte- en tijd-heat maps
Safety Helmet (Hard Hat) Detection
Detecteert tot 30 personen, tot 4 afgeschermde regio’s
Metadata & Regionaal People Counting
Metadata: inbraak, lijn/gebied detectie, gezichtscaptatie, multi-target detectie
Regionaal tellen: 8 regio’s, 3 modi (dichtheid, afwijking, wachttijd), instelbare triggers en uploads
On/Off Duty Detectie
Tot 8 regio’s, 2 modi: afwezigheid, aan/uit dienst
Instelbare parameters: aanwezigheid, afwezigheidsduur
Algemeen
Voeding met -1T: 12?VDC ±20% 1,22?A / 24?VAC ±20% 0,88?A, PoE 802.3at Type 2 Class 4 max. 16,8?W
Zonder -1T: 12?VDC ±20% 1,28?A / 24?VAC ±20% 0,91?A, PoE max. 15,2?W
Materiaal: behuizing metaaldelen
Afmetingen: Ø?144,3?mm ×?114,1?mm
Gewicht: 970?g (2,14?lb), met verpakking ca. 1461?g (3,23?lb)
Opslagcondities: -40?°C tot?65?°C, ≤?95% RH (niet-condenserend)
Bedrijfstemperatuur: met -H: -40?°C tot?65?°C; zonder: -30?°C tot?65?°C; ≤?95% RH
33 talen waaronder Nederlands
Heartbeat, één-toets reset, mirror, wachtwoordbeveiliging
Kabel: 0,25?m
Heater: bij -H uitvoering
Ondersteunt alarmbox (DS-FM2466) voor 6 extra in-/uitgangen in LAN
Goedkeuringen
EMC (CE-EMC, RCM, IC, KC), Veiligheid (CB, CE-LVD, BIS, LOA), Milieu (RoHS, WEEE, Reach)
Bescherming: IP67, IK10, Anti-corrosie (-Y: NEMA?4X), spoor/automotive EN50121-4
PVC-vrij
