Thermische maximale resolutie
256 × 192
Thermische module beeldsensor
Vanadiumoxide, ongekoelde brandpuntsvlakdetector
Pixelafstand
12μm
NETD
Minder dan 40 mK (@25°C), F#=1.0
MRAD
3,33 mrad
Gezichtsveld (FOV)
50,0° × 37,3° (H × V)
Minimale scherpstelafstand
0,5 m
Diafragma
F1.0
Brandpuntsafstand
3,6 mm
Respons-golfband
8μm tot 14μm
Optische module resolutie
2688 × 1520
Beeldsensor
1/2.7" Progressive Scan CMOS
Minimale verlichting:
Kleur: 0,05 Lux @ (F1.6, AGC AAN)
Z/W: 0,01 Lux @ (F1.6, AGC AAN)
Gezichtsveld
83,7° × 43° (H × V)
Diafragma:
F1.6
WDR
120 dB
Sluitertijd
1s tot 1/100.000s
Dag & Nacht
Infraroodfilter met automatische omschakeling
Brandpuntsafstand
4,27 mm
Slimme functies
Video-inhoudsanalyse (VCA):
4 VCA-regeltypes (Lijnoverschrijding, Inbraak, Regio binnenkomst, en Regio verlaten)
Tot 8 VCA-regels
Temperatuurmeting:
3 typen regels, 21 regels (10 punten, 10 regio's, 1 lijn)
Temperatuurbereik: -20°C tot 650°C (-4°F tot 1202°F)
Nauwkeurigheid: Max (±2°C, ±2%)
IR-afstand: Tot 30 m
IR-intensiteit en -hoek
Automatisch aangepast
Netwerk Hoofdstream Thermisch:
25 fps bij 1280 × 720, 704 × 576, 640 × 512, 320 × 240
Netwerk Hoofdstream Optisch:
50Hz: 25 fps bij 2688 × 1520, 1920 × 1080, 1280 × 720
60Hz: 30 fps bij dezelfde resoluties
Thermisch:
25 fps bij 704 × 576, 640 × 512, 320 × 240
Substream Optisch:
50Hz: 25 fps bij 704 × 576, 352 × 288
60Hz: 30 fps bij 704 × 480, 352 × 240
Video-compressie:
H.265/H.264/MJPEG, H.265+/H.264+ (Baseline/Main/High Profiel)
Audio-compressie:
G.711u/G.711a/G.722.1/MP2L2/G.726/PCM
Ondersteunde protocollen:
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Live weergave gelijktijdig
Tot 20 streams
Gebruikersniveaus
Tot 32 gebruikers (beheerder, operator, gebruiker)
Beveiligingsmaatregelen:
Gebruikersauthenticatie (ID en wachtwoord), MAC-adresbinding, HTTPS-versleuteling, IEEE 802.1x toegangscontrole, IP-filtering
Integratie
Alarminvoer
2 kanalen (0 tot 5 VDC)
Alarmuitgang
2 relaisuitgangen, acties instelbaar
Alarminstelling
SD-kaartopname, relaisuitgang, slimme opname, FTP-upload, e-mailmelding
Audio-ingang:
1 x 3.5mm microfoon/lijn-in (2–2.4V[p-p], 1kΩ ±10%)
Audio-uitgang:
Lineair niveau; impedantie: 600 Ω
Netwerkinterface:
1 x RJ45 10M/100M zelfaanpassende Ethernetpoort
SD-kaart:
Micro SD/SDHC/SDXC tot 256 GB, ondersteunt handmatige of alarmopname
Software & Clients
API-ondersteuning: ISAPI, HIKVISION SDK, ondersteuning voor derde partijen
Clientsoftware:
iVMS-4200
Webbrowser-ondersteuning:
Google Chrome 57+, Mozilla Firefox 52+, Internet Explorer 10+, Safari 12+ (Mac)
Algemeen
Taalmenu
Ondersteunt 33 talen, waaronder Nederlands
Voeding
100-240 VAC, PoE (802.3af)
Stroomverbruik
Max. 8W
Werktemperatuur/-vochtigheid
-40°C tot 60°C, tot 90% RV
Beschermingsklasse:
IP68, TVS 6000V bliksem-/overspannings-/spanningsbeveiliging
Afmetingen
286.7 mm × 175.2 mm × 150.1 mm
Gewicht
Ongeveer 5,85 kg
Certificeringen
EMC: CE-EMC, RCM, IC
Veiligheid
CB, CE-LVD, BIS
Bescherming:
IP68: IEC 60529
Explosieveiligheid:
ATEX: II 2 G Ex db IIC T6 Gb / II 2 D Ex tb IIIC T80°C Db
IECEx: Ex db IIC T6 Gb / Ex tb IIIC T80°C Db
Anti-corrosie bescherming
NEMA 4X (volgens NEMA 250-2018), corrosiebeschermingsniveau C5
