Device Interfaces
Input Interface: | Exit Button*1, Door Magnetic*1, and
Wiegand*1
Output Interface: | Lock*1, Alarm Out*1
Communication Mode: | RS-485
General
Power Supply: | 12VDC
Indicator: | 7 Indicators (RS-485 Communication Status*2, Power Supply*1,
Exit Button*1, Lock Status*1, Door Magnetic*1 and Running
Status*1)
Installation: | Wall Mounting
Working Temperature : | -30°C to +55°C (-22°F to 131°F)
Working Humidity: | 10% to 90% (Non-Condensing)
Dimensions (L×W×H): | 48×115×25mm (1.89×4.53×0.98inch)
